MERCEDES-BENZ C220 (202.022)
1993 to 1997
Notes and Illustrations
2199 cm3
, DOHC 16V
Engine and cooling system
Type
Capacity (cm3) / number of cylinders
Compression ratio / pressurebar
Oil pressurebar
Oil temperatureºC
Valve clearance – inletmm
Valve clearance – exhaustmm
Firing order
No 1 cylinder position
Thermostat opening temperatureºC
Radiator cap pressurebar
Fuel system
Idle speed – manual [auto]rpm
Fast idle speed – manual [auto]rpm
CO @ idle speed [3000 rpm] – see page VI%
HC @ idle speed [3000 rpm] – see page VIppm
CO2 @ idle speed [3000 rpm] – see page VI%
O2 @ idle speed [3000 rpm] – see page VI%
Carburettor / fuel injection
Type / ref
Main jet / needle
Injection pressurebar
Pump pressurebar
Octane ratingRON
Ignition system
Type
Ignition coil
Primary resistanceohms
Ballast resistorohms
Voltage – Tmnl 15(+) to earthV
Distributor
Points gap (air gap)mm
Dwell angleº (%)
Condenser capacityµF
Rotation
Ignition timing – basic [staticº Crankshaft @ rpm
V = Vacuum    NV = No Vacuum
Total ignition advanceº Crankshaft @ rpm
º Crankshaft @ rpm
º Crankshaft @ rpm
Centrifugal check.º Crankshaft @ rpm
º Crankshaft @ rpm
º Crankshaft @ rpm
Vacuum range checkmbar
Maximum vacuum advanceº Crankshaft
Spark plugs
Type
Electrode gapmm
Electrical system
BatteryV / CC / RC
Alternator voltage / full load current / engine rpm
Starter motor current / voltage – crankingA / V
Starter motor current / voltage – lockedA / V
Running gear
Brakes –
Front (min. friction material thickness)mm
Rear (min. friction material thickness)mm
Tyres
SaloonSize
Estate / VanSize
Pressure – front / rear – Saloonbar
Pressure – front / rear – Estate / Vanbar
Front suspension / wheel alignment
Toe-in (+) / Toe-out (–)mm [º]
Camber
Castor
King pin inclination
Rear suspension / wheel alignment
Toe-in (+) / Toe-out (–)mm [º]
Camber
Torque wrench settings
Cylinder head – stage 1Nm
Cylinder head – stage 2Nm
Cylinder head – stage 3Nm
Cylinder head – stage 4Nm
Big-end bearingsNm
Main bearingsNm
Clutch coverNm
Flywheel [driveplate]Nm
Front hubsNm
Rear hubsNm
Wheel nuts / boltsNm
Spark plugsNm
Capacities
Engine oil & filterlitres
Gearbox – 4-speed [5-speed]litres
Automatic transmission – refilllitres
Final drivelitres
Cooling systemlitres
Fuel tanklitres
111.961 DOHC 16V 110kW
2199 / 4
10.0 / ≥10.5
0.3 [3.0 @ 3000rpm]
80
0: Hyd.
0: Hyd.
1-3-4-2
F
87 ±2°
1.40 ±0.10
700 to 800 N/A
_
≤0.3
≤200
_
_
_Bosch
HFM
_
3.2 to 36
_
95[U]
Computerized
_
0.3 to 0.6
_
Battery
_
_
_
_
_
Computer control N/A
_
Computer control
_
_
Computer control
_
_
Computer control
_
Bosch/Champion
F8DCO / C10YCC
0.80
12V 62AH
14.0 / 90 / _
75 / 11.5
_
2.0
2.0
195/65×15: 205/60×15
_
2.1 / 2.3
_
[+20’ ±10’]
– 35’ ±20’. Sport: -55’±20’
4°40’±30. Sport: 5°10’±30’
_
+0°33’ ±7’
_
55. Bolt length ≤105mm
+ 90°
+ 90°
_
30, + 90 to 100°
55, + 90 to 100°
25
30, + 90 to 100°
WSM
200 to 240
110
25 to 30
5.8
1.5
5.5
1.1
8.3
62
